Practical and Reliable Mechanicals • Non-Corrosive Materials
Delivered at the right price
Killing Line ConveyorsStandard Features
Variable Speed, reversible control; Corrosion resistant aluminum gear box, drive sprocket, take up wheel. Stainless steel input (1/2” diameter) and output shafts (1” diameter). Stainless steel 1” x 1” x .065 square diamond track. Coil link drive chain - sprocket calibrated, case hardened with bright zinc finish. 3/4 HP motor, 115V 60 HZ. Trolleys: Hi-density poly wheels; stainless steel brackets and fasteners. Upgrades available: Wash proof motor; stainless steel drive chain.
Stainless Steel Killing TunnelStandard Features
Two models are available to work with either KILL16 or KILL22 killing line conveyors. Birds are killed as they enter the tunnel on shackles. The tunnel base is tapered with a drain hole. Both sides have wash nozzles with trigger valves and hose to keep tunnel washed down at intervals.
Stunning KnifeStandard Features
Stunned birds are easier to handle and they bleed more quickly and thoroughly. Stunned birds have fewer bruises and broken wings. You speed up your processing operation. You can control voltage to various ages and sizes of birds or for changing environmental conditions. Virtually the only way to kill turkey.
Maximum Production in Limited Space,
A Fast, Thorough Scald
#1-LoadedReady to Start Scald Cycle
Consider the ease in loading -- no basket to open or shackles to load. Just push the start button to begin operation. Timer automatically resets to desired time.
#2-Position AfterPlatform has Made about 1/4 of a Cycle
Birds are dumped to bottom of tank. The water level backs up ahead of platform as it turns. Then, water sprays through holes in platform onto birds, giving a spray-action scald.
#3-Position AfterPlatform has made 1/2 of a cycle.
Birds are completely submerged -- not confined in any way but free to tumble in all positions thus assuring a thorough scald.
#4-Birds are TumbledThrough the Water
By the revolving platform and then out of the water to the stop position. The platform rotates at 10 RPM and will rotate several times depending on length of scald.
#5-Out of the WaterAnd Ready for Picking
The water will drain away, yet birds will not dry out if not picked immediately. No lids or shackles to hamper unloading.
We Offer ModelsWith Three Capacities
Each of the three is available in either stainless steel or galvanized materials. The mechanicals are the same for all models.
STANDARD FEATURES: Digital Timer: 0 to 5 minutes, can be set to read in seconds; Dial Thermostat: sensitive to within 1 degree F; Automatic Pilot provides for igniting the main burner(s), to shut off the supply to the main burner(s) and to the pilot burner in case the pilot flame is out; Water Level Control; Work Table: A dial thermometer is optional. The cost is the same for either propane (LP) or for natural gas but please specify. 50 Hz(5 cycle) available but needs to be quoted separately. A 6 inch(15.25 cm) non-mechanized exhaust is required (standard, single wall flue pipe, preferably stainless steel). Fully assembled.
Even When They Are Empty,
Our Pickers are Loaded...
We offer models with two capacities. Both are available in either stainless steel or galvanized materials. The mechanicals are identical for both units.
STANDARD FEATURES: Digital Timer, 0-5 minutes, can be set to read in seconds; Automatic Door is self closing; latch is operated by start button which starts the timer and opens automatic water valve; door opens automatically at the end of pick cycle; Feather Exhaust. Centrifuges are heavy spun aluminum. A bird catch table (stainless steel on both models) is optional. 50 Hz (50 cycle) is available but needs to be quoted separately. Fully assembled.
Our conical shaped centrifuge allows birds to rotate freely for a clean pick.
Is Self Closing
SP30 PickerAutomatic Door Detail
Water Flushed TroughStandard Features
Stainless steel, 30 inch (76 cm) width, 12 inch (30 cm) depth. EV16 - 10 foot (3 meters) long. EV22 - 15 foot (4.6 meters) long. Trigger valve and hose: EV16 - two on one side; 2 total; EV22 - two on each side; 4 total Gooseneck nozzle: EV16 - one on each side 2 total; EV22 - two on each side; 4 total Giblet Station: 20” wide x 33” long x 37 1/2” high (51 cm x 84 cm x 95 cm) Splash Shield: To reduce splash, mount at user’s discretion; 48” (122 cm) x 60” (152 cm); 20 gauge CONVEYORS: The conveyors are the same as our Killing Line Conveyors. EV16 - 34 shackle spaces; EV22 - 44 shackle spaces. ESSSR and TCOMBE shackle options. Order shackles separately
Eviscerating TableHandy Accessory
For miscellaneous prep work.
ESSSR ShackleTCOMBE Shackle
Gizzard PeelerStainless Steel
Hardened, spiral cut rolls are direct driven. 1 1/3 HP motor with gear reducer turns the rolls at 288 rpm. Double pole switch allows you to reverse the rolls. Housing, peeler rolls, stainless steel; frame, stand aluminum 19” wide x 33” long x 40 1/2” high (48 cm wide x 84 cm long x 103 cm high).
On Farm Processing
Adjustable Bleed RackFor Killing Cones
Four leveling feet; easy rack height adjustment up to 60” (152 cm); Can be disassembled and stored flat. Designed to straddle 2’ W x 1’ H x 4’ L stock tank for blood collection (order separately). All stainless steel. Slotted rail designed to hold these cones: 54K - 6; 53K - 8 (for most pastured poultry broilers); 8 to 10 52K; 10-51K. Each cone requires a QRBT1A bracket (order separately). Bracket comes with SS fasteners but you must drill two holes for attachment.
All four sizes constructed of 20 gauge stainless steel. Hemmed edges and lock formed seams assure no snags.
Manual Gas ScaldersWe offer models with two capacities.
Both are available in either stainless steel or galvanized materials. The mechanicals are identical for both units. With galvanized materials, the tanks are hot dipped galvanized post fabrication. STANDARD FEATURES Water level and heat controls. Easily accessible pilot light. Drain table can be mounted on side or at the end. Drain table adds 26” (66 cm) of length or width. The cost is the same for either propane (LP) or natural gas but please specify. Pilotstat and pilot burner form an automatic pilot for igniting the main burner. They also shut off the gas supply to the main burner and to the pilot burner in case pilot flame is extinguished. A 6 inch (15.25 cm) non-mechanized exhaust is required (standard, single wall flue pipe, preferably stainless steel). 120/220V 50/60 HZ 1Ph. Fully assembled.
Scalding BasketPlastic Coated
These baskets are a big asset in speeding up your manual scalding operation. Heavy wire is coated with tough vinyl plastic.
An economical picker for small operations, pastured poultry and general farm use. Will pick most species of birds including turkey (depending on the size - one turkey at a time). Will readily pick 100 birds per hour. Feather exhaust, water spray ring around top perimeter, manual timer. All stainless steel construction. Unquestionably, greater longevity than smaller poly pickers. Universal Appeal - we have sold this one in many corners of the USA, the Caribbean, Central and South America, the Middle East and Africa! Ships 2 per skid.
A versatile table for any processing operation. Use as the primary table for smaller operations. Use for small clean up jobs at larger installations. One piece top with 1” (2.54 cm) lip; 1.75” (4.4 cm) center drain. Two gooseneck wash valves and two trigger valves with hose. All stainless steel.
ESSSR and TCOMBE shackle options. Order shackles separately.
Automatic Bagging And Closing
Bagger blows open bags. Vacuum removes air from bag before sealing (not shrink wrap). Includes twist tie sealer - vinyl coated wire is pulled off of a reel, is cut to size and then twisted around neck of bag. A very fast and efficient system. Capacity of up to 10 packages per minute.
S128 Killing Knife, Stainless Steel Blade.
S130 Pinning Knife, Stainless Steel Blade.
475 Trimmer. Stainless Steel 8” (20 cm) Blades. Ergonomic Design. Ambidextrous. Adjustable Tension.
726 Boning Knife. High Carbon Steel, Hardened and Tempered. Genuine Hardwood Handle.
Clung Chicken Lung Remover 11” Long (28 cm)
Tlung Turkey Lung Remover 15” Long (38 cm)
Designed for optimal air flow. Stackable. Easily washed and sanitized. High density polyethylene. Shipped knocked down but all snap together components. Assembly takes about 3 minutes with no tools. Door 12 1/2” wide x 16 1/2” long (31.8 cm wide x 42 cm long). Hand holds. 10 broiler capacity.
We have Processing Plans which include operating tips, manning suggestions and floor plans for three sizes of plants -- up to 400 broilers per hour, up to 600 broilers per hour and up to 1000 broilers per hour. Plans are available online, www.browerequip.com, or contact us. The equipment units in these plans are as follows (substitute as you like - any equipment can be used).
There are 3 Processing Plans
To Choose From...
Poultry Processing Video 1 Presentation
Small Commercial Plant
The video shows equipment we would propose for production of about 1000 birds per hour. The processes shown would be similar for say about 600 birds per hour (using a smaller capacity scalder and picker)
Poultry Processing Video 2 Presentation
On Farm Processing
The video shows equipment we would propose for on farm processing of say about 100 birds per hour.
Poultry Processing Video 3 Presentation
This video is a demonstration of our Bagging Machine
